YBM Series Prefabricated Substation

YBM Series Prefabricated Substation: Smart Power Distribution Solution

The YBM Series Prefabricated Substation is small and of high quality, as it is put together in the workshop. This unit has high-voltage switchgear (6–35kV), transformers (315–2500kVA), and low-voltage distribution equipment (0.4kV) all in one waterproof case. Our substations take 60% less time to place and take up 30% less room than standard solutions. They were made with help from the Tianjin Electric Drive Institute and more than 100 partner companies. It has an IP54 rating for security, can handle 25kA of short-circuit current, and is expected to last 30 years. It is certified by ISO 9001, ISO 14001, and OHSAS 45001, and is reliable enough for businesses.

What Makes This Substation Different?

Factory-Built Quality Control

Traditional substations take months to build on-site. Weather delays, quality inconsistencies, and labor challenges create headaches.

Our product changes this completely.

Every component is assembled in our climate-controlled facility. We use over 120 sets of advanced machinery—including CNC automatic winding machines and microcomputer-controlled gradient curing furnaces. This controlled environment ensures consistent quality you can trust.

Your substation arrives ready for connection. Installation takes days, not months.

Smart Grid Integration

The modern power grid demands intelligence. Your YBM Series Prefabricated Substation delivers exactly that.

Built-in monitoring systems track current, voltage, power, and transformer temperature in real-time. You get four remote functions: telemetry, signaling, control, and adjustment.

Fault detection works automatically. The system isolates problematic sections, transfers loads, and restores power within one minute. No manual intervention needed.

This smart functionality connects seamlessly with SCADA systems. You manage your entire distribution network from a centralized location.

Space-Saving Design

There are special problems that come up in cities. It costs money to have space. It takes time to get building permits.

Both issues are fixed by our flexible design.

The small size takes up 30% less room than regular substations. Each useful compartment is made up of separate modules. The high voltage, transformer, and low voltage parts all work on their own, but they fit together perfectly.

Need more space in the future? The low-voltage section is simple to make bigger. You don't have to start from scratch to meet new power needs.

Extreme Environment Performance

The conditions at your centre are bad. Changes in temperature, wetness, dust, and mechanical effects can all make something less reliable.

We've built security into every part of this.

The cover is made of galvanized steel and has a polyester powder finish that gives it IP54 protection and IK10 mechanical impact resistance. ASTM B117 salt spray testing proves that the product is ready for use in coastal areas. Thermal cycling tests from -40°C to +50°C show that it can be used all year.

High-quality cold-rolled grain-oriented silicon steel is used in the body of the transformer. Insulating oil made from plants is better at controlling temperature. At elevations of up to 2000 meters, these materials work reliably.

Technical Specifications

Key Advantages for Your Project

Faster Deployment

Time is money in power infrastructure projects.

Traditional substations require extensive site preparation, foundation work, and assembly. Weather delays extend timelines. Labor coordination creates complexity.

Your project benefits from 60% faster installation. We complete manufacturing and testing before shipment. You reduce on-site construction from 6-12 months to 2-4 weeks.

This speed advantage helps you meet tight project deadlines and energize facilities faster.

Enhanced Safety Features

Electrical systems can't put safety at risk.

Our design includes mechanical interlocks and safety features that stop people from accidentally using it. Construction that is resistant to arcs meets IAC AFLR classification standards. Fire suppression systems have smoke detectors that work with SCADA and CO2 pumps for generator rooms.

The fibre cement or metal cage is very resistant to fire. The materials are eco-friendly and can be recycled, which meets today's standards for sustainability.

Resistance stays below 1 ohm in ground grid devices. As a result, both people and tools are kept safe during fault situations.

Proven Quality Management

Long-term dependability is based on quality.

We follow the idea of "zero defects" at every stage of production. Every part is overseen by our 15 senior engineers and 30+ junior techs. Tests and assembly are done by seventeen top techs.

Getting raw materials starts with qualifying the suppliers. Problems are found before production starts during incoming review. The steps used in manufacturing are very specific. Prior to storage, a finished product review checks that all of the requirements have been met.

This all-around method stops bad goods from getting to your site. You get tools that does exactly what it's supposed to do.

Complete Project Support

Your needs extend beyond just equipment.

We provide comprehensive one-stop solutions for power supply and distribution. Our team assists with product selection, system design, and procurement of complementary equipment.

Installation support ensures proper commissioning. Training programs help your personnel operate and maintain the substation effectively.

With 18 patents and 20+ years of industry experience, we bring proven expertise to your project.

Real-World Applications

Municipal Infrastructure

Rail transit systems demand absolute reliability. Power interruptions affect public safety and service quality.

We've delivered solutions for Xuzhou Rail Transit Network Control Center and Xuzhou High-speed Railway East Station. Dual-circuit power supply designs ensure uninterrupted operation.

Xuzhou New Health Hospital Phase I relies on our substations for critical medical equipment power.

Commercial Developments

Shopping complexes, entertainment venues, and residential projects need scalable power infrastructure.

Our substations serve Xinhuai Central Complex, Huaihai Xintiandi developments, Zhongjun Huijingcheng, and Xuzhou Fantawild Adventure. The Tianyu Yayuan project achieved top quality assessment results using our equipment.

Industrial Facilities

Manufacturing requires reliable, high-capacity power distribution.

XCMG Group factory power supply upgrades used our solutions. GCL Photovoltaic Industrial Park, Huaihai Biomedical Industrial Park, and multiple technology parks benefit from our substations.

These projects were completed ahead of schedule while maintaining rigorous quality standards.

FAQ

Q: What maintenance does the substation require?

Schedule maintenance every 3 years. This includes transformer oil analysis per ASTM D924 standards, switchgear contact inspection, and protection relay functional testing. The design minimizes maintenance requirements while ensuring reliable 30-year operation.

Q: How does the substation handle extreme weather?

We conduct comprehensive environmental qualification testing. Salt spray testing per ASTM B117 validates coastal application performance. Thermal cycling from -40°C to +50°C per IEC 60068-2 confirms temperature resilience. UV radiation resistance testing ensures 20-year exterior finish durability.

Q: Is seismic protection included?

Yes. Seismic qualification follows IEEE 693 standards with testing to 0.5g horizontal and 0.33g vertical acceleration. Modal analysis and time history testing verify structural integrity and continued electrical function during seismic events.

Q: What about electromagnetic interference?

EMI suppression incorporates shielded cable design and grounding grid systems. We comply with IEC 61000-6-4 emission standards and IEC 61000-6-2 immunity requirements. CISPR testing protocols verify performance.

Q: How effective is the fire protection system?

CO2 suppression systems protect transformer compartments. Smoke detection integrates with SCADA systems for immediate alerts. Fire-resistant barriers provide 2-hour protection, validated through UL 723 flame spread testing and NFPA 850 compliance verification.

Q: Can I monitor the substation remotely?

Absolutely. Built-in comprehensive monitoring provides real-time data on current, voltage, power, and temperature. Remote communication enables telemetry, signaling, control, and adjustment functions from your centralized control location.

Why Choose Xuzhou Tuojie?

Our dedication goes beyond making products.

We stay ahead of changes in the industry by investing in research and development and having 18 patents. Modern production technology guarantees high-quality work. We strictly follow the ISO 9001 standards for our quality control system.

We've finished a huge number of important power projects in the business, industry, and municipal sectors. Our approach to making products and helping customers is shaped by this experience.

You get custom options that are made to fit your needs. Our expert team helps you from the first meeting to the delivery and beyond.

Our dedication to quality and the environment is backed up by international standards like ISO 9001, ISO 14001, and OHSAS 45001. All low-voltage equipment and cables are certified by the National CCC.

Contact Us

Ready to Transform Your YBM Series Prefabricated Substation Power Infrastructure? Get expert guidance for your project. Contact us at tuojie@electricinchina.com for technical specifications and customized solutions.
