DC Power Supply Panel

1.Also known as DC power panel for critical sites.
2.Provides stable DC power for power plants and substations.
3.Converts AC to DC via high-frequency switching modules.
4.Charges batteries to maintain backup power during outages.

Send Inquiry download

Product Description

Details

DC Power Supply Panel for Critical Infrastructure - Enterprise-Grade Solutions

A DC Power Supply Panel is your best friend when your building needs power that doesn't go out for mission-critical tasks. Power plants, substations, phone networks, and industrial control systems can all use our enterprise-grade panels to get secure, controlled DC power. These panels have advanced high-frequency switching units that change AC to stable DC output. They also keep the batteries charged all the time so that they can be used as a backup when the power goes out. Our systems have a N+1 modular redundancy design, microprocessor-based intelligent control, and full safety circuits. They have efficiency scores of over 92% and power factors of over 0.99. We offer solutions that keep your essential systems online 99.99% of the time, backed by 18 patents and over 20 years of manufacturing excellence.

Why Choose Our DC Power Solutions?

Unmatched Reliability for Your Operations

You are aware that downtime is expensive in addition to being inconvenient. Our panels use clever redundancy to remove single points of failure. Your system keeps running even if one module requires repair.

Before leaving our plant, every unit is put through a thorough testing process. From raw material inspection to final delivery, we apply ISO 9001 quality requirements throughout the whole production process.

Intelligent Management Features

Modern infrastructure demands smart solutions. Our product systems offer:

Real-time monitoring of voltage, current, and battery status
Automated charging and discharging management
Remote telemetry, signaling, control, and adjustment capabilities
Alarm management with customizable thresholds
Unattended operation suitable for unmanned substations

Your maintenance team receives instant notifications about system status. This proactive approach prevents minor issues from becoming major failures.

PATENT CERTIFICATE

Space-Efficient Design

We know your equipment room space is valuable. Our compact panel-mounted configuration maximizes power density while minimizing footprint. Front-accessible controls simplify installation and maintenance without requiring rear access.

Technical Specifications

Parameter	Specification
Input Voltage	AC 380V±20%, three-phase four-wire
Output Voltage	DC 110V / 220V (configurable)
Output Current	10A - 600A (customizable)
Efficiency	≥92% at rated load
Power Factor	≥0.99
Voltage Regulation	≤±0.5% (from no load to full load)
Ripple Coefficient	≤0.5%
Module Redundancy	N+1 hot-swappable design
Protection Rating	IP20 - IP54 (depending on environment)
Operating Temperature	-10°C to +45°C (extended range available)
Control Method	Microprocessor-based intelligent control
Communication Interface	RS485, Ethernet, SNMP protocol
Battery Management	Intelligent charging with temperature compensation
Display	LCD touchscreen with parameter setting
Certifications	ISO 9001, ISO 14001, OHSAS 45001, CCC

Core Advantages That Matter to You

Power Assurance You Can Trust

The power needs to stay on for your circuit breakers, relay safety systems, and control equipment. That's exactly what we offer. No matter how the grid or the load changes, our panels keep the DC power fixed.

When the power goes out, emergency lighting systems turn on right away. You can count on your control systems to work when you need them the most.

High-Efficiency Performance

Having to pay more for energy can hurt your business. It means that our panels lose less energy and heat than 92% of the time. In real life, this means that parts need less cooling and last longer.

The high power factor (0.99) lowers reactive power, which makes the general use of electricity in your building more efficient.

Modular Redundancy Design

It doesn't change how you run your business if one area fails. You will always have extra space because we have N+1 backups. You can switch out parts that are "hot-swappable" while the system is still working, without having to stop.

This approach to design comes from having used it in real life. It's very important for places like the Xuzhou Rail Transit Network Control Center and XCMG Group to be able to count on the power we provide.

PRODUCTION EQUIPMENT

Applications Across Industries

Power Generation and Distribution

Substations and power plants depend on our panels for control power. These environments demand equipment that withstands electromagnetic interference, voltage transients, and temperature extremes.

We've successfully deployed systems at Xuzhou High-speed Railway East Station, where dual-circuit designs ensure absolute safety for rail operations.

Telecommunications Infrastructure

Cell towers and switching equipment require -48VDC systems with seamless battery backup. Our panels maintain operation during grid failures, with designs rated for seismic zones and temperature ranges from -40°C to +65°C.

Industrial Automation

Manufacturing facilities use our 24VDC panels for PLC systems, motor drives, and safety circuits. These environments present challenges: dust, vibration, and EMI. Our panels meet IP54 protection standards and include advanced filtering.

We've completed projects at GCL Photovoltaic Industrial Park and High-Tech Industrial Park, delivering solutions ahead of schedule while maintaining quality excellence.

Commercial Infrastructure

Modern commercial buildings integrate our panels into building management systems. Projects like Xinhuai Central Complex and Huaihai Xintiandi benefit from our centralized power distribution approach.

Application areas

Our Manufacturing Excellence

Advanced Production Capabilities

We operate over 120 sets of state-of-the-art equipment:

CNC automatic winding machines for precision transformer production
CNC static vacuum casting machines for superior insulation
Microcomputer-controlled gradient curing furnaces
Automated testing systems for quality verification

Expert Technical Team

Our innovation comes from people. With 15 senior engineers, over 30 intermediate technicians, and 17 senior technicians, we maintain deep expertise in DC Power Supply Panel power electronics and electrical engineering.

This team has secured 18 patents, demonstrating our commitment to technological advancement.

Comprehensive Quality Management

Quality isn't a checkpoint—it's a philosophy. We implement "zero defects" thinking throughout:

Raw material verification from certified suppliers
In-process inspection at critical production stages
Comprehensive testing of finished products
Final verification before packaging and shipment

Every panel receives performance testing under various load conditions. We document results for full traceability.

FAQ

Q: What causes voltage drift in DC power panels over time?

Voltage shift is usually caused by parts wearing out or changes in temperature. We deal with this by using voltage standards that are adjusted for temperature and suggesting that they be calibrated once a year. Our screens keep the voltage accurate to within ±0.5% for the whole time they are in use.

Q: How do I determine the correct battery backup duration?

Find the total DC load current and multiply it by the number of backup hours you need. Size the battery's capacity at 80% depth of drain to get the longest life. Based on your unique load profile, our technical team helps you with these estimates.

Q: Why might rectifier modules generate excessive heat?

Problems with heat generally mean that there isn't enough air flow, the system is overloaded beyond its 80% rated capacity, or parts are breaking down. Our panels have features for tracking temperatures and setting off alarms. For the best results, we suggest keeping the temperature below 40°C.

Q: Can I integrate your panels with existing monitoring systems?

Yes. Our panels support multiple communication protocols including RS485, Ethernet, and SNMP. We provide protocol documentation and technical support for integration with SCADA systems and building management platforms.

Q: What maintenance schedule do you recommend?

Perform visual inspections quarterly. Check electrical connections semi-annually. Conduct comprehensive testing and calibration annually. Battery health assessment should occur every six months. We provide detailed maintenance guides with each installation.

Q: How quickly can failed modules be replaced?

Our hot-swappable design allows module replacement in under 10 minutes without system shutdown. We maintain spare module inventory and offer rapid-response service agreements for critical installations.

Customization for Your Requirements

Standard products don't always fit unique applications. We provide:

Custom voltage and current ratings
Environmental hardening for extreme conditions
Specific communication protocol integration
Specialized mounting configurations
Extended temperature range components
Seismic qualification for critical infrastructure

Our engineering team collaborates with you from concept through commissioning. We've adapted solutions for diverse conditions across municipal, commercial, and industrial sectors.

Why Partner With Us?

Proven Track Record

Over two decades, we've delivered hundreds of successful projects:

Xuzhou New Health Hospital Phase I
Xuzhou Fantawild Adventure theme park
Huaihai Biomedical Industrial Park
Electronic Industrial Park installations

These projects demonstrate our capability to meet stringent deadlines while maintaining quality standards.

PARTNERS

Complete Solution Provider

Beyond manufacturing panels, we assist with additional product procurement. This one-stop approach simplifies your project management and ensures component compatibility.

Certifications You Require

All products carry necessary certifications:

ISO 9001 Quality Management
ISO 14001 Environmental Management
OHSAS 45001 Occupational Health and Safety
CCC Mandatory Certification for electrical products

These credentials verify our commitment to international standards and continuous improvement.

Certificate

Service Philosophy

"Technology first, service paramount, and integrity fundamental" guides our operations. We prioritize your interests through:

Responsive technical support
Transparent communication
Realistic timelines and commitments
Post-installation training and documentation
Long-term partnership approach

Contact Us

Ready to enhance your DC Power Supply Panel facility's power reliability? Our team is prepared to discuss your specific requirements and develop a tailored solution.

CUSTOMER CASE

SHARE TO

Intentional inquiry

Online Message

Research team
