SCBH15 High Efficiency Amorphous Transformer

1.Versatile Application: Suitable for substations and key power nodes.
2.Low Loss: Amorphous alloy reduces no-load energy waste.
3.Safe & Fire-Resistant: Oil-free, self-extinguishing, suitable for crowded areas.
4.Durable: Moisture-proof, crack-resistant, lowers maintenance costs.
5.Wide Demand Coverage: Supports airports, stations, factories, and power plants.
6.Energy Efficient: Amorphous material saves significant long-term electricity.
7.Reliable: Oil-free and flame-retardant for high fire-safety areas.
8.Highly Adaptable: Stable, maintenance-free, suitable for all environments.

Send Inquiry download

Product Description

Details

SCBH15 High Efficiency Amorphous Transformer - Advanced Energy-Saving Solution

Superior Performance You Can Trust

The SCBH15 High Efficiency Amorphous Transformer from Xuzhou Tuojie International Trade represents cutting-edge power distribution technology. Our transformer achieves 70-80% lower no-load losses compared to traditional silicon steel units. With H-class insulation rated to 180°C and efficiency exceeding 98.5% at rated load, it delivers exceptional performance. Our technical team—15 senior engineers and over 30 intermediate technicians—has developed this solution backed by 18 patents. Operating across capacities from 30KVA to 31,500KVA, this dry-type transformer eliminates fire risks while maintaining sound levels below 45dB for enhanced urban compatibility.

Dry type transformer

What Makes Our Amorphous Transformer Different?

Revolutionary Core Technology

Your facility demands reliability. That's why we've engineered our transformers with amorphous metal cores featuring 1.56T magnetic flux density. This innovative material reduces core losses to just 0.17W/kg at 50Hz.

You'll notice immediate benefits:

Energy consumption drops by 30-40% in continuous operation
No-load losses decrease by 70% compared to conventional designs
Long-term electricity costs reduce significantly
Environmental impact minimizes through reduced carbon emissions

Fire-Safe Dry-Type Design

Traditional oil-filled transformers pose risks you shouldn't accept. Our oil-free design offers peace of mind.

The cast resin encapsulation provides:

Self-extinguishing, flame-retardant properties meeting IEC 60076
IP20-IP23 protection against environmental factors
Safe installation directly at load centers
Zero pollution risk to surrounding areas
Perfect for hospitals, schools, and crowded facilities

Built for Demanding Environments

Your operations can't afford downtime. We've designed these transformers to excel in challenging conditions.

Environmental resilience includes:

Operation from -40°C to +40°C ambient temperature
95% humidity tolerance without performance degradation
Excellent moisture resistance at 100% humidity
Coastal area capability with salt spray resistance
Immediate restart after shutdown—no pre-drying needed

Technical Specifications

Parameter	Specification
Product Model	SCB11, SCB12, SCB13, SCB14, SCB18
Type	Dry-type
Phase	Three Phase
Frequency	50Hz / 60Hz
Cooling Method	AN / AF
Rated Capacity	30KVA – 31,500KVA
Primary Voltage	10 / 20 / 35kV
Secondary Voltage	0.22 – 1.14kV
Vector Group	Dyn11 / Yyn0 / Yd11
Insulation Class	F / H (optional)
Winding Material	Copper / Aluminum
Core Material	Amorphous Alloy / Grain-oriented Silicon Steel
Design Standard	IEC60076 / ANSI / IEEE / GB / CSA
Certifications	ISO9001, ISO14001, OHSAS45001
Altitude	≤4,000m
Ambient Temperature	-40°C ~ +40°C
Humidity	≤95%
Temperature Rise	100K (windings), 80K (core)
Efficiency	≥98.5% at rated load
Sound Level	<45dB (up to 630kVA)
Short Circuit Impedance	4-6%
Design Life	30+ years

Where Your Transformer Excels?

Urban Power Distribution Networks

You need compact solutions for city substations. Space is limited. Noise restrictions are strict.

Our 315kVA-2500kVA units deliver:

Minimal footprint for tight installations
Quiet operation meeting urban noise standards
30-40% energy savings over transformer lifetime
Safe operation near residential areas

Industrial Facilities

Your data center, hospital, or manufacturing plant requires 99.9% reliability. Downtime costs thousands per minute.

The SCBH15 High Efficiency Amorphous Transformer provides:

Superior thermal performance for continuous operation
150% overload capacity for 30 minutes during peak demand
Excellent harmonic handling from variable frequency drives
K-factor ratings up to K-13 for non-linear loads
Stable performance under voltage fluctuations

Renewable Energy Integration

Your wind farm or solar installation operates in remote locations. Maintenance visits are expensive.

Our transformers offer:

Zero maintenance requirements validated through field testing
Custom voltage and impedance matching for PV inverters
Grid code compliance for seamless integration
Excellent efficiency across varying load conditions
Reliable operation in extreme environmental exposure

Proven Quality and Manufacturing Excellence

World-Class Production Capabilities

You deserve manufacturing precision. Our 120+ sets of advanced equipment ensure it.

Our facilities include:

CNC automatic winding machines for consistent quality
CNC static vacuum casting machines for perfect encapsulation
Automatic foil winding machines for optimal conductor placement
Microcomputer-controlled gradient curing furnaces for superior resin bonding

Rigorous Quality Management

Every transformer undergoes comprehensive inspection. We follow ISO9001 standards across all stages.

Your quality assurance includes:

Raw material verification before production
In-process monitoring at every manufacturing step
Complete finished product testing
Pre-delivery inspection and documentation
Installation support and commissioning guidance

Our "zero defects" philosophy means unqualified products never leave our facility.

Certificate

Extensive Project Experience

We've delivered hundreds of key projects across three decades. Your success builds on our proven track record.

Municipal projects include:

Xuzhou Rail Transit Network Control Center with dual-circuit safety design
Xuzhou High-speed Railway East Station power systems
Xuzhou New Health Hospital Phase I critical load distribution

Commercial installations encompass:

Xinhuai Central Complex
Huaihai Xintiandi Phases 7-8
Xuzhou Fantawild Adventure

Industrial applications feature:

XCMG Group factory power supply upgrades
GCL Photovoltaic Industrial Park
Huaihai Biomedical Industrial Park

CUSTOMER CASE

Key Advantages for Your Operations

Energy Efficiency You Can Measure

Payback period of 3-5 years through reduced losses
2-3% higher efficiency at 25-75% loads where transformers typically operate
Validated performance per IEEE C57.120 efficiency standards

Safety Without Compromise

Non-flammable, fire-resistant construction
Seismic qualification to IEEE 693 standards
Safe for installation in load centers and populated areas

Maintenance Freedom

Annual visual inspection only
Quinquennial thermographic surveys
No oil sampling or core maintenance
Accelerated aging tests per IEC 60076-11 confirm longevity

Superior Reliability

50-year design life
Extended service life in harsh industrial environments
Superior performance under non-linear loads
Excellent overload capacity for peak demand periods

FAQ

Q1: What maintenance is required for your amorphous core transformers?

Your product requires only annual visual inspection and quinquennial thermographic surveys. No oil sampling or core maintenance is needed. This maintenance-free operation is validated through accelerated aging tests per IEC 60076-11 standards.

Q2: How does efficiency compare to silicon steel transformers throughout the load cycle?

Independent testing shows 2-3% higher efficiency at 25-75% loads where most transformers operate. This translates to significant energy savings with payback periods of 3-5 years through reduced losses, confirmed by IEEE C57.120 efficiency standards.

Q3: Can these transformers handle harmonic distortion from VFDs and LED lighting?

Absolutely. K-factor ratings up to K-13 accommodate harmonic-rich loads without derating. The superior thermal performance is validated through harmonic load testing per IEEE C57.110 guidelines. Your variable frequency drives and modern lighting systems operate safely.

Q4: What is the expected service life compared to conventional transformers?

Design life exceeds 30 years with proper application. This longevity is supported by accelerated thermal aging tests and field experience data from installations dating to the 1990s, meeting IEC 60076-7 loading guides.

Q5: How do these transformers perform in seismic zones and extreme weather conditions?

Seismic qualification to IEEE 693 standards ensures operation during earthquakes. Environmental testing per IEC 60068 confirms performance from -40°C to +50°C. Enhanced moisture resistance surpasses conventional dry-type units for coastal and humid environments.

Q6: Is the SCBH15 suitable for photovoltaic and grid-connected applications?

Yes. We support custom voltage, impedance, connection group, and IP protection to match PV inverters and grid standards. The transformer delivers stable, reliable performance. It's widely used in solar power plants and new energy projects worldwide.

Why Choose Xuzhou Tuojie International Trade?

Strong Technical Foundation

15 senior engineers driving innovation
Over 30 intermediate technicians ensuring quality
17 senior technicians providing installation expertise
18 patents demonstrating technological leadership

Comprehensive Service Approach

Tailored solutions for your specific requirements
Complete transformer solutions from design to commissioning
Additional product procurement assistance
Customer-focused philosophy: "technology first, service paramount, integrity fundamental"

International Standards Compliance

ISO 9001, ISO 14001, OHSAS 45001 certifications
National CCC Mandatory Certification for all products
IEC60076, ANSI, IEEE, GB, CSA design standard options
CE certification for international markets

Proven Global Delivery

Over 20 years of industry experience
Hundreds of successful key power projects
Timely delivery with ahead-of-schedule completion track record
Comprehensive one-stop power supply and distribution solutions

PATENT CERTIFICATE

Contact Us

Ready to reduce SCBH15 High Efficiency Amorphous Transformer energy costs and enhance safety? Contact our team for personalized transformer solutions tailored to your specific requirements.

Email: tuojie@electricinchina.com

SHARE TO

Intentional inquiry

Online Message

Research team
